AND Force Tester Model : MCT-1150 (Japan)

AND Force Tester Model : MCT-1150 (Japan)

฿165,000.000

Specification:
Max Force Capacity : 500 N
Crosshead stroke : 400 mm
Load display resolution : 0.1N
Effective stroke : 315mm
Crosshead speed : 10-300mm/min: Within 5% of the set value *2
Dimensions (W × D × H) : 250 × 405 × 711 mm
Standard Accessories
– Load Cell 500 N (Accuracy : ±0.2% of Full Scale)
– Included software : MCT-Logger&operate touch panel + USB cable



หมวดหมู่: ,

คำอธิบาย

Specifications
Model MCT-1150
(General purpose model)		 MCT-2150
(High performance model)
Table / floor model Table model
Maximum capacity 500N
Crosshead stroke 400mm 370mm
Effective stroke*1 315mm 285mm
Crosshead speed 10-300mm/min: Within 5% of the set value*2
Crosshead speed setting Digital setting: 1mm/min increments within the above range
Crosshead speed and load capacity Full speed range at maximum capacity
Crosshead return speed Three speed settings: 10, 100, 300mm/min
Load measurement accuracy ±0.2% F.S 500N to 50N: ±0.2% F.S
50N to 5N: Within 2% of indicator value
5N and lower: Within 0.1N
Load display resolution 0.1N 0.01N (0.1N will display for values over 100N)
Load calibration Auto-zero function (calibration unnecessary)
Displacement display 000.0mm (Min. 0.1mm) 00.00mm (Min 0.01mm: 0.1mm
will display for values over 100mm)
Included software MSAT-Lite, MCT-Logger
Safety mechanisms 1. Upper and lower displacement stroke limits
2. Overload limit (automatic shutdown when load cell passes 105% of rated capacity)
3. Emergency stop switch
Dimensions (W × D × H) 250 × 405 × 711mm
Weight 17kg 18kg
Power supply AC90 to 240V 1Ø 50/60Hz
Power consumption 90W
Operating ambient condition Temperature: 5 to 40°C Humidity: 20 to 80%RH
Recommended ambient conditions Temperature: 23 ±2°C Humidity: 50 ±10%RH
Standard equipment Instruction manual, 500N capacity load cell, computer software (CD-ROM), USB cable
